The safety guardian and efficient enabler of outdoor high-voltage power grids

In outdoor high-voltage power distribution systems, 40.5KV serves as the core voltage level in the medium-high voltage domain, undertaking critical tasks such as power transmission, equipment maintenance isolation, and fault protection. The 40.5KV outdoor disconnect switch is an indispensable "safety guardian" and "operation assistant" in this system. It is exposed to the complex outdoor environment all year round, facing the tests of wind, rain, dust, and alternating temperatures. With stable performance and reliable structure, it builds the first line of defense for the safe and efficient operation of substations, transmission lines, and new energy power stations, serving as the core hub equipment connecting power production and transmission.

As the core category of outdoor high-voltage electrical equipment for 50Hz AC, the 40.5KV outdoor disconnect switch is primarily positioned for "no-load opening and closing" and "electrical isolation". In simple terms, it is mainly used for the opening and closing operations of high-voltage lines in no-load conditions, and can effectively isolate electrical equipment such as high-voltage busbars and circuit breakers that need maintenance, as well as live power lines, cutting off the power circuit, providing a safe maintenance environment for maintenance personnel and avoiding safety hazards caused by live operations. Additionally, it can also be used to open and close small-capacity capacitors or inductors, meeting the practical operational needs of various outdoor high-voltage scenarios, and is a core basic equipment for ensuring the safety of power grid operation.

Unlike indoor high-voltage equipment, the 40.5KV outdoor disconnector needs to withstand various extreme natural environments for a long time. Therefore, its structural design and technical processes are all centered around the three core aspects of "weather resistance, reliability, and easy operation and maintenance". In terms of structural design, this type of disconnector mostly adopts a V-shaped structure. The single pole is fixed on the base by two pillar insulators, with a reasonable intersection angle. It is combined with core components such as the connection seat, contact head part, grounding knife, grounding static contact, and connection terminals to form a complete operation system. Among them, the grounding system is divided into three types: no grounding, single grounding, and double grounding. A reliable mechanical interlock is set between the main shaft and the grounding knife, and an auxiliary switch is equipped to effectively prevent misoperation and ensure the accuracy and safety of the opening and closing states, avoiding power grid faults caused by operational errors [1].

The upgrading of technical processes is the core support for the 40.5KV outdoor disconnector to adapt to the complex outdoor environment. In the transmission system, a combination of rolling bearings and umbrella gear mechanism is adopted, which not only enables the switch to rotate flexibly and open and close freely, making the operation more effortless, but also ensures the consistency of the two-column opening and closing actions, avoiding jamming and misalignment problems; the setting of the opening and closing limit device can ensure that the contacts are in the optimal position, and the handle is locked by the locking ring after operation, preventing accidental external forces from causing free opening and closing, further enhancing the operational reliability. In terms of material selection, the contacts mostly use military-grade silver oxide tin (AgSnO₂) composite materials, which have stable contact resistance and excellent conductivity, effectively reducing line loss; the insulators adopt high-strength silicone rubber or ceramic materials, with excellent insulation performance, large contact gap, and sufficient margin of insulation isolation breaks, which can effectively resist outdoor insulation aging, leakage, etc. At the same time, the surface is treated with a special anti-corrosion coating, with a coating thickness far exceeding industry standards, which can effectively resist the erosion of salt fog, acid rain, and sand dust, and pass through strict salt fog tests and ultraviolet aging tests, suitable for various extreme outdoor environments such as high humidity coastal areas, high wind-sand deserts, and high-altitude mountains.
